Hardware Software Interface (HSI) Spec. Page: 17 / 19
SR7300/SR7300OSE Document Version [2.01]
Request Status Char. & Sample Status answer Char. & Sample
“i0” ("@1?i0", 0x0D) LEFT LEVEL i0XX (“@1i010”0x0D)
“i1” ("@1?i1", 0x0D) RIGHT LEVEL i1XX
“i2” ("@1?i2", 0x0D) CENTER LEVEL i2XX
“i3” ("@1?i3", 0x0D) SUBWF LEVEL i3XX
“i4” ("@1?i4", 0x0D) SURR L LEVEL i4XX
“i5” ("@1?i5", 0x0D) SURR R LEVEL i5XX
“i6” ("@1?i6", 0x0D) BACK L (or 1ch) LEVEL i6XX
CHANNEL LEVEL
[
XX: ( 0=”10”)
(+01=”11”~+10=”20”)
(-01=”09”~ -10=”00”)
(-11=”55” ~ -15=”51”)
]
“i7” ("@1?i7", 0x0D) BACK R LEVEL i7XX
“j0” ("@1?j0", 0x0D) LEFT DISTANCE j0XX
“j1” ("@1?j1”, 0x0D) RIGHT DISTANCE j1XX
“j2” ("@1?j2", 0x0D) CENTER DISTANCE j2XX
“j3” ("@1?j3", 0x0D) SUBWF DISTANCE j3XX
“j4” ("@1?j4", 0x0D) SURR. L DISTANCE j4XX
“j5” ("@1?j5", 0x0D) SURR. R DISTANCE j5XX
“j6” ("@1?j6", 0x0D) BACK L DISTANCE j6XX
SPEAKER DISTANCE
[
XX: (00～30)
(1 foot = “01”)
(10 feet=”10”)
]
“j7” ("@1?j7", 0x0D) BACK R DISTANCE j7XX
FRONT LAGE k00
“k0” ("@1?k0", 0x0D)
FRONT SMALL k01
CENTER LAGE k10
CENTER SMALL k11
“k1” ("@1?k1", 0x0D)
CENTER OFF k12
SUBWF ON k20
“k2” ("@1?k2", 0x0D)
SUBWF OFF k22
SURR. LAGE k30
SURR. SMALL k31
“k3” ("@1?k3", 0x0D)
SURR. OFF k32
BACK LAGE k40
BACK SMALL k41
SPEAKER SIZE
“k4” ("@1?k4", 0x0D)
BACK OFF k42
BACK 1ch l0
BACK 2ch l1
SPEAKER BACK ‘l’ ("@1?l", 0x0D)
BACK NONE l2
SPEAKER A OFF o0
SPEAKER A ‘o’ (“@1?o”,0x0D)
SPEAKER A ON o1
SPEAKER B OFF p0
SPEAKER B ‘p’ (“@1?p”,0x0D)
SPEAKER B ON p1
MAIN+SUB q0
MAIN q1
BILINGUAL ‘q’ ("@1?q",0x0D)
SUB q2
AUDIO MUTE OFF r0
AUDIO MUTE ‘r’(“@1?r”,0x0D)
AUDIO MUTE ON r1
VIDEO MUTE OFF s0
VIDEO MUTE ‘s’ (“@1?s”,0x0D)
VIDEO MUTE ON s1
