Hardware Software Interface (HSI) Spec. Page: 8 / 19
SR7300/SR7300OSE Document Version [2.01]
3-4. Command list
3-4-1. Normal Command list
(Samples indicated the ID set to as ‘1’.)
Command Character Sample
POWER A0 "@1A0",0x0D
POWER ON A1 "@1A1",0x0D
POWER
POWER OFF A2 "@1A2",0x0D
DSS B0 "@1B0",0x0D
TV B1 "@1B1",0x0D
LD B2 "@1B2",0x0D
DVD B3 "@1B3",0x0D
VCR1 B4 "@1B4",0x0D
VCR2／DVD-R
B5
"@1B5",0x0D
AUX1 B6 "@1B6",0x0D
AUX2 B7 "@1B7",0x0D
DVD-R B8 "@1B8",0x0D
CD B9 "@1B9",0x0D
TAPE BA "@1BA",0x0D
CD-R BB "@1BB",0x0D
FM BC "@1BC",0x0D
AM BD "@1BD”,0x0D
MW BE "@1BE”,0x0D
LW BF "@1BF",0x0D
INPUT SELECT
TUNER BG "@1BG",0x0D
MULTI-CHANNEL INPUT ON
BH
"@1BH",0x0D
MULTI-CHANNEL
MULTI-CHANNEL INPUT OFF
BI
"@1BI",0x0D
INPUT SIGNAL A/D
BJ
"@1BJ",0x0D
Multi Room control command as from MULTI ROOM
Command Character Sample
DSS Ba "@1Ba",0x0D
TV Bb "@1Bb",0x0D
LD Bc "@1Bc",0x0D
DVD Bd "@1Bd",0x0D
VCR1 Be "@1Be",0x0D
VCR2／DVD-R
Bf
"@1Bf",0x0D
AUX1 Bg "@1Bg",0x0D
AUX2 Bh "@1Bh",0x0D
DVD-R Bi "@1Bi",0x0D
CD Bj "@1Bj",0x0D
TAPE Bk "@1Bk",0x0D
CD-R Bl "@1Bl",0x0D
FM Bm "@1Bm",0x0D
AM Bn "@1Bn”,0x0D
MW Bo "@1Bo”,0x0D
LW Bp "@1Bp",0x0D
INPUT SELECT
TUNER Bq "@1Bq",0x0D
INPUT SIGNAL A/D
Br
"@1Br",0x0D
