59
Note : Step4, 5 is to check if CPU software is capable of DSP
code. "Software Type No" is to show what "DSP Code
Group" CPU is capable of. And vice versa.
Step 8 is to manage the 16 codes for DSP.
• When the unit is once turned into Service Mode, the
unit keeps this mode until the main power is turned
off. (Turning into stand-by mode does not make it
quit from Service Mode.) When the unit quits from
Service Mode, Information in the memory is also
cleared and the unit returns to the status when it is
out from the factory.
Product Reset
To reset the back up memory of the unit into the default status,
follow the procedure below.
1. Turn of the unit and press SELECT and
S-DIRECT
button
simultaneously more than 1.5 seconds.
2. After "DEFAULT" is displayed on FLD, power is turned off
once and turned of again, EEPROM is cleared to the default
status, µ-com is reset and the unit returns to the normal
status. (Software Serial Number will not be cleared.)
Note : When the unit is shipped from the factory, the procedure
above must be done to set the unit to initial status after
the tests.
Personal notes:
