Marantz SR7400 - Page 58

NOTE : "nsp" PART IS LISTED FOR REFERENCE ONLY, MARANTZ WILL NOT SUPPLY THESE PARTS.
74
POS. NO
VERS.
COLOR
PART NO.
(FOR EUR)
DESCRIPTION
PART NO.
(MJI)
CN81 nsp nsp JACK MOLEX53014-0610 KJP06GA19ZM
CN82 YP04000760 YP04000760 JACK MOLEX35328-02 KJP02GA89ZM
CN83 YP04000760 YP04000760 JACK MOLEX35328-02 KJP02GA89ZM
D101 nsp *HD201750R DIODE TW 1N4003 KVD1N4003SRT
IC11 HC10230090 HC10230090 IC NJM2584D HVINJM2584D
IC12 HC10230090 HC10230090 IC NJM2581D HVINJM2581D
IC13 HC10230090 HC10230090 IC NJM2584D HVINJM2584D
J101
nsp nsp JUMPER SN95/PB5 , 0.6 C3A206
J120
JK11 *YT003210R *YT003210R TERMINAL 3P,G/B/R,SILVER CJJ4S030Z
JK12 *YT003210R *YT003210R TERMINAL 3P,G/B/R,SILVER CJJ4S030Z
JK13 *YT003210R *YT003210R TERMINAL 3P,G/B/R,SILVER CJJ4S030Z
JK14 *YT003670R *YT003670R TERMINAL CJJ5P012Z
JK15 *YT003660R *YT003660R TERMINAL SILVER PLATE CJJ4P045Z
JK16 *YT003660R *YT003660R TERMINAL SILVER PLATE CJJ4P045Z
Q101 HT30001000 HT30001000 TRS. KTC3199YT HVTKTC3199YT
Q102 *HT600040R *HT600040R TRS. KTA1267YT HVTKTA1267YT
Q103 *HT600040R *HT600040R TRS. KTA1267YT HVTKTA1267YT
R101 nsp nsp RES.
75Ω 1/6W J
CRD20TJ750T
R102 nsp nsp RES.
75Ω 1/6W J
CRD20TJ750T
R103 nsp nsp RES.
75Ω 1/6W J
CRD20TJ750T
R104 nsp nsp RES.
75Ω 1/6W J
CRD20TJ750T
R105 nsp nsp RES.
75Ω 1/6W J
CRD20TJ750T
R106 nsp nsp RES.
75Ω 1/6W J
CRD20TJ750T
R107 nsp nsp RES.
75Ω 1/6W J
CRD20TJ750T
R108 nsp nsp RES.
75Ω 1/6W J
CRD20TJ750T
R109 nsp nsp RES.
75Ω 1/6W J
CRD20TJ750T
R110 nsp nsp RES.
1MΩ 1/6W J
CRD20TJ105T
R111 nsp nsp RES.
1MΩ 1/6W J
CRD20TJ105T
R116 nsp nsp RES.
1MΩ 1/6W J
CRD20TJ105T
R118 nsp nsp RES.
1MΩ 1/6W J
CRD20TJ105T
R121 nsp nsp RES.
12kΩ 1/6W J
CRD20TJ123T
R122 nsp nsp RES.
10kΩ 1/6W J
CRD20TJ103T
R123 nsp nsp RES.
470Ω 1/6W J
CRD20TJ471T
R124 nsp nsp RES.
470Ω 1/6W J
CRD20TJ471T
R125 nsp nsp RES.
470Ω 1/6W J
CRD20TJ471T
R126 nsp nsp RES.
10kΩ 1/6W J
CRD20TJ103T
R130 nsp nsp RES.
10Ω 1W J
KRG1SANJ100RT
R131 nsp nsp RES.
10Ω 1W J
KRG1SANJ100RT
R132 nsp nsp RES.
10kΩ 1/6W J
CRD20TJ103T
R133 nsp nsp RES.
10kΩ 1/6W J
CRD20TJ103T
R134 nsp nsp RES.
220Ω 1/4W J
CRD25TJ221T
R135 nsp nsp RES.
330Ω 1/4W J
CRD25TJ331T
RY11 LY20240490 LY20240490 RELAY 5GPA-28 DC24 HSL3B013ZE
DSP PCB (CUP11658Z)
BC11 nsp nsp JUMPER SN95/PB5 , 0.6 C3A206
BC12 nsp nsp JUMPER SN95/PB5 , 0.6 C3A206
BC13 nsp nsp JUMPER SN95/PB5 , 0.6 C3A206
BN33 nsp nsp JACK MOLEX53014-0710 KJP07GA19ZM
C101 nsp OA47601640 ELECT. CAP. 47µF 16V HCEA1CH470T
C102 nsp DK96103300 CER. CAP. 0.01µF HCUS1H103KC
C103 nsp OA47601640 ELECT. CAP. 47µF 16V HCEA1CH470T
C104 nsp DK96103300 CER. CAP. 0.01µF HCUS1H103KC
C105 nsp OA47601640 ELECT. CAP. 47µF 16V HCEA1CH470T
C106 nsp DK96103300 CER. CAP. 0.01µF HCUS1H103KC
