Marantz SR8000 - Page 31

55
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
001B 7000
/K1B,
/N1B
996500003422 FRONT AL PANEL BLACK 320J248010
001B 7000
/K1G,
/N1G
996500003436 FRONT AL PANEL GOLD 320J248110
001B 7000
/U1B
FRONT AL PANEL
STANDBY BLACK
320J248020
001B 7000
/U1G
FRONT AL PANEL
STNDBY GOLD
320J248120
001B 8000
/K1G,
/S1G
FRONT AL PANEL GOLD 321J248110
001B 8000
/U1B
FRONT AL PANEL
STANDBY BLACK
321J248020
002B 482245411825 BADGE MARANTZ BADGE 185J251010
005B BLACK 996500003426 CHASSIS FRONT MOLD BLK 320J105020
005B GOLD 996500003437 CHASSIS FRONT MOLD GOLD 320J105120
006B MASK WINDOW SHEET 312J303050
007B 996500003427 WINDOW 312J158110
008B 996500003428 REFLECTOR LED 320J274010
009B MASK L R C LFE LS S RS 312J303020
010B BLACK 996500003429 BUTTON FUNCTION BLACK 320J270010
010B GOLD 996500003441 BUTTON FUNCTION GOLD 320J270110
011B BLACK 996500003430 BUTTON TUNING BLACK 320J270020
011B GOLD 996500003442 BUTTON TUNING GOLD 320J270120
012B BLACK 996500003431 BUTTON CENTER ESC. BLACK 320J270030
012B GOLD 996500003443 BUTTON CENTER ESC. GOLD 320J270130
013B HOLDER FL 183J271020
014B STICKER ADHESIVE FOR FL 056J122010
019B WASHER D16 T0.5 261J012010
025B WASHER D16 T0.5 261J012010
030B BLACK 996500003432 KNOB MASTER BLACK 312J154010
030B GOLD 996500001391 KNOB MASTER GOLD 312J154020
031B BLACK 996500003433 LENS IR BLACK 275W355010
031B GOLD 996500001392 LENS IR GOLD 275W355110
032B GOLD MASK IR 312J303030
033B 996500001393 LENS STANDBY LENS 312J355010
034B /K,/N,/S 996500001394 JOINT POWER 312J125010
035B BLACK 996500001975 BUTTON POWER SW BLACK 255W270010
035B GOLD 996500001395 BUTTON POWER SW GOLD 255W270110
035B /U1B
ONLY
BUTTON POWER SW TACT
BLACK
320J270040
035B /U1G
ONLY
BUTTON POWER SW TACT
GOLD
320J270140
009G 482246242129 LEG FRONT SIDE 183J057010
010G 482246242048 LEG REAR SIDE 183J057110
915G /U BUSHING AC CORD 450H259010
J001 /K,/N,/S 482226731964 JACK MAINS INLET SOT-17 YJ04002250
J001 /K,/N,/S 996500001313 JACK MAINS INLET PWI1910-H YJ04002440
L001 7000
/K,
MAINS TRANSF. EI96-80T
PIN TYPE 220V 50Hz
TS19630170
L001 7000
/N
996500003410 MAINS TRANSF. EI96-80T
PIN TYPE 230V 50Hz
TS19630180
L001 7000
/U
MAINS TRANSF. EI96-80T
PIN TYPE 120V 60Hz
TS19630160
L001 8000
/K
MAINS TRANSF. EI105-80T
220N 50Hz 60Hz
TS60513180
L001 8000
/S
MAINS TRANSF. EI105-80T
230V 50Hz
TS60513190
L001 8000
/U
MAINS TRANSF. EI105-80T
120V 60Hz
TS60513170
L003 /K,/N,/U FERRITE CORE TFCK-25-15-12 FC50250020
W001 /U MAINS CORD UL CSA
NON-INTEGRAL
YC02000880
PACKING
001T 7000/K USER GUIDE SR7000 320J851350
001T 7000/N 996500003434 USER GUIDE SR7000 320J851310
001T 7000/U USER GUIDE SR7000 320J851250
001T 7000/K USER GUIDE SR8000 321J851360
001T 7000/S USER GUIDE SR8000 321J851350
001T 7000/U USER GUIDE SR8000 321J851250
Z001 7000 996500003420 REMOTE COMMANDER
RC7000SR
ZK320J0010
Z001 8000 REMOTE COMMANDER
RC18SR
ZK300J0010
Z007 /K MAINS CORD
CCEE 10A 250V
ZC01803110
Z007 /K MAINS CORD
CCEE 10A 250V
ZC01803090
Z007 /N MAINS CORD
10A 250V CLASS2
ZC01803120
Z007 /N MAINS CORD
10A 250V CLASS2
ZC01803080
Z007 /S MAINS CORD
10A 250V
ZC01804080
Z007 /S MAINS CORD
10A 250V
ZC01804070
SERVICE KIT
Z100 996500003435 EXTENSION WIRES *SR7000JIG
( 5P, 7P, 8P, 10P, 12Px2 )
* Refer to WIRING DIAGRAM
REMARK :
1
FOR SR7000 ( Lot number
from 01 to 12 ) and SR8000
( Lot number from 01 to 09 )
2
FOR SR7000 ( Lot number
from 13 ) and SR8000 ( Lot
number from 10 )
NOT STANDARD SPARE
PARTS
001S 7000 PACKING CASE 320J801010
001S 8000 PACKING CASE 321J801010
002S CUSHION LEFT 310J809010
003S CUSHION RIGHT 310J809020
Z002 LR6AG CP4 ZF53104000
Z003 /K,/N,/S EXT.ANTENNA FM 931222R ZA02800020
Z003 /U EXT.ANTENNA FM ZA02000070
Z004 LOOP ANT COIL LA-700HB LA00055010
Z005 /U PLUG ANT ADAPTOR YP90000310
Z006 /K JACK AC ADAPTER
SMK S-I6116 PLRTY
YJ04001240
1
1
1
1
2
2
2
2
482232111439
996500003421
