Marantz SR8000 - Page 58

82
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(FOR PCS)
DESCRIPTION
PART NO.
(MJI)
PU44-SUB FRONT
CIRCUIT BOARD
PU44-CAPACITORS
CU81 482212610364 CER. 100pF UP050B101K-A DA16101110
CU82 482212610364 CER. 100pF UP050B101K-A DA16101110
PU44-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W :
RU81-RU89
PU44-SEMICONDUCTORS
DU81 482213011569 L.E.D. HLMF-K200 #2UL RED HI10005340
QU81 482213041947 TRS. 2SC2458 2SC1740S
2SC3199 ETC.
HT30001000
QU82 482213041947 TRS. 2SC2458 2SC1740S
2SC3199 ETC.
HT30001000
QU83 482213060588 DIG.TRS.
DTC114ES UN4211 10K 10K
BA20001000
PU44-MISCELLANEOUS
SU81 996500001349 ROTARY SWITCH ROT ENCOD
EC16B 16PLS 16CLICK
SR02010080
PU54-TACT POWER SW
CIRCUIT BOARD FOR U
SU91 /U 996500000373 PUSH SWITCH EVQ11L05R SP01013370
PW04-H.P. CIRCUIT BOARD
CW01 /K,/N,/S 482212230043 CER. 0.01µF Z 50V DK18103310
CW02 /K,/N,/S 482212230043 CER. 0.01µF Z 50V DK18103310
CW03 482212230043 CER. 0.01µF Z 50V DK18103310
CW04 482212230043 CER. 0.01µF Z 50V DK18103310
JW01 BLACK 482226510685 JACK HLJ2307-01-3160 YJ01004240
JW01 GOLD 482226511525 JACK HLJ2307-01-3163 YJ01004330
PY04-CONNECTOR P-SUPPLY
CIRCUIT BOARD
PY04-CAPACITORS
C801 482212612453 CER. 0.01µF Z E 500V DK18103560
C802 996500003388 ELECT 15000µF 63V LH6 EB15906320
C802 8000 ELECT 27000µF 63V (LH6) EB27906330
C803 996500003388 ELECT 15000µF 63V LH6 EB15906320
C803 8000 ELECT 27000µF 63V (LH6) EB27906330
C821 482212230043 CER. 0.01µF Z 50V DK18103310
C822 482212230043 CER. 0.01µF Z 50V DK18103310
C823 482212411583 ELECT. 2200µF M 35V RA-2 OA22803520
C824 482212411583 ELECT. 2200µF M 35V RA-2 OA22803520
C825
482212230043 CER. 0.01µF Z 50V DK18103310
C828
C829 482212412328 ELECT. 6800µF 16V RA2 OA68801620
C830 482212440723 ELECT. 2200µF 16V OA22801620
C831
482212230043 CER. 0.01µF Z 50V DK18103310
C834
C835 482212490354 ELECT. 100µF M 16V RA-2 OA10701620
C836 482212490354 ELECT. 100µF M 16V RA-2 OA10701620
C837 482212230043 CER. 0.01µF Z 50V DK18103310
C838 482212230043 CER. 0.01µF Z 50V DK18103310
C839 482212230043 CER. 0.01µF Z 50V DK18103310
C840 482212490354 ELECT. 100µF M 16V RA-2 OA10701620
C841 482212490354 ELECT. 100µF M 16V RA-2 OA10701620
C842 482212490354 ELECT. 100µF M 16V RA-2 OA10701620
C843 482212230043 CER. 0.01µF Z 50V DK18103310
CN01 482212240617 CER. 0.1µF +80%-20% 50V DC DD38104010
CN02 482212441539 ELECT. 47µF M 16V RA-2 OA47601620
CN03 482212240617 CER. 0.1µF +80%-20% 50V DC DD38104010
CN04 482212441539 ELECT. 47µF M 16V RA-2 OA47601620
CN05 482212441543 ELECT. 1µF M 50V RA-2 OA10505020
CN06 482212240617 CER. 0.1µF +80%-20% 50V DC DD38104010
CN07 482212490353 ELECT. 100µF M 10V RA-2 OA10701020
CN08 482212490362 ELECT. 22µF M 50V RA-2 OA22605020
CN09 482212440763 ELECT. 2.2µF M 50V RA-2 OA22505020
CY01 482212240617 CER. 0.1µF +80%-20% 50V DC DD38104010
CY02 482212611726 CER. 2200pF DA17222110
CY03 482212240617 CER. 0.1µF +80%-20% 50V DC DD38104010
CY04 482212611726 CER. 2200pF DA17222110
CY05 482212230043 CER. 0.01µF Z 50V DK18103310
CY06 482212230043 CER. 0.01µF Z 50V DK18103310
CY07 /K,/S,/U 532212421731 ELECT. 10µF 50V RA-2 OA10605020
CY07 /N 482212480543 ELECT. 10µF 35V ARS OA10603540
CY08 /K,/S,/U 532212421731 ELECT. 10µF 50V RA-2 OA10605020
CY08 /N 482212480543 ELECT. 10µF 35V ARS OA10603540
CY11 /K,/S,/U 532212421731 ELECT. 10µF 50V RA-2 OA10605020
CY11 /N 482212480543 ELECT. 10µF 35V ARS OA10603540
CY12 /K,/S,/U 532212421731 ELECT. 10µF 50V RA-2 OA10605020
CY12 /N 482212480543 ELECT. 10µF 35V ARS OA10603540
CY13
482212230043 CER. 0.01µF Z 50V DK18103310
CY22
PY04-RESISTORS
R821
JUMPER 75060501P0
R824
RN01 482205023303 33kΩ J 1/4W GG05333140
RN08 482205021503 15kΩ ±5% 1/2W GG05153120
RN27 482205310331 330Ω ±5% 1W GA05331010
RN28 482205310331 330Ω ±5% 1W GA05331010
RN29 482205210101 100Ω ±5% 1/6W GG05101160
RY17 JUMPER 75060501P0
RY18 JUMPER 75060501P0
RY21 /K,/N,/S JUMPER 75060501P0
PL74-RESISTORS (COMMON)
CARBON FILM FIXED RES.
±5% 1/6W :
RN02-RN07 RN09-RN26
RY01-RY14 RY19-RY20
RY22-RY25
PY04-SEMICONDUCTORS
D801 996500003398 DIODE SIP 10A 200V HE20024290
D821 482213033057 DIODE HE20011290
D822 482213033057 DIODE HE20011290
D823 482213082421 DIODE 1D3 1A 200V HD20002710
D824 482213082421 DIODE 1D3 1A 200V HD20002710
D825 482213082421 DIODE 1D3 1A 200V HD20002710
D853 482213082421 DIODE 1D3 1A 200V HD20002710
D854 482213082421 DIODE 1D3 1A 200V HD20002710
DN01 482213082421 DIODE 1D3 1A 200V HD20002710
DN02 482213082421 DIODE 1D3 1A 200V HD20002710
DN03 482213080837 DIODE HSS81TD 150V 150mA HD20027010
DN04
482213082421 DIODE 1D3 1A 200V HD20002710
DN07
DY01
482213032362 DIODE 1SS176 MA165 1SS254 HD20002000
DY10 30V 0.1A
Q821 482220983317 IC NJM7815FA +15V 1A HC38915090
Q822 482220961256 IC NJM7915FA HC39915090
Q823 482220983824 IC NJM7805FA +5V HC38905090
Q824 482220983824 IC NJM7805FA +5V HC38905090
