Marantz ST6000 - Diodes; Integrated Circuit; Transistors

POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
POS.
NO
VERS.
COLOR
PART NO.
(PCS)
DESCRIPTION
PART NO.
(MJI)
SUB CIRCUIT BOARD
CAPACITORS
C901 nsp CER. 0.1 F 50V Z nsp
C902 nsp ELECT 1000 F 6.3V nsp
C903 nsp CER. 0.1 F 50V Z nsp
C911 nsp CER. 22pF 50V J nsp
C912 nsp CER. 15pF 50V J nsp
C913 nsp CER. 12pF 50V J nsp
C914 nsp CER. 10pF 50V J nsp
C923 nsp ELECT 10 F 35V nsp
C924 nsp ELECT 1 F 50V nsp
C925 nsp CER. 0.1 F 50V Z nsp
C926 nsp ELECT 22 F 25V nsp
C927 nsp ELECT 1 F 50V nsp
C929 nsp CER. 0.01 F 50V Z nsp
DIODES
D901 4822 130 11608 LED RED SLR342VCF02 *HI100810R
D902 4822 130 11608 LED RED SLR342VCF02 *HI100810R
D903 4822 130 11608 LED RED SLR342VCF02 *HI100810R
D905 4822 130 11608 LED RED SLR342VCF02 *HI100810R
D906 4822 130 11608 LED RED SLR342VCF02 *HI100810R
D910
9965 000 01250 1SS131M *HD201290R
D914
INTEGRATED CIRCUIT
IC91 9965 000 01463 MICROPROCESSOR
TMP87CM78F-xxxx
*HU100350R
IC92 9965 000 01464 VOLTAGE DETECTOR
RE5VL30CA-TZ
*HC105150R
TRANSISTORS
Q901 4822 130 62503 DTC114YS *BA000730R
Q902 4822 130 62503 DTC114YS *BA000730R
Q903 4822 130 62503 DTC114YS *BA000730R
Q905 4822 130 62503 DTC114YS *BA000730R
Q906 4822 130 62503 DTC114YS *BA000730R
Q911 4822 130 62787 DTA114YS *BA000190R
Q912 4822 130 62503 DTC114YS *BA000730R
Q913 4822 130 60107 2SA933SR HT109331S0
Q914 4822 130 62503 DTC114YS *BA000730R
RESISTORS
RA91 nsp 100 k x 5 NETWORK nsp
R751 U nsp 3.3M 1/2W nsp
R901 nsp 390 1/5W nsp
R902 nsp 390 1/5W nsp
R903 nsp 390 1/5W nsp
R905 nsp 390 1/5W nsp
R906 nsp 390 1/5W nsp
R908
nsp 47k 1/5W nsp
R912
R920
nsp 47k 1/5W nsp
R923
R931 nsp 1M 1/5W nsp
R951 nsp 1.2k 1/5W nsp
R952 nsp 100k 1/5W nsp
R953 nsp 390k 1/5W nsp
R954 nsp 1.2k 1/5W nsp
R955 nsp 100k 1/5W nsp
R956 nsp 1.2k 1/5W nsp
R957 nsp 4.7k 1/5W nsp
R958 nsp 22k 1/5W nsp
R959 nsp 470 1/5W nsp
R960 nsp 47k 1/5W nsp
R961 nsp 47k 1/5W nsp
R962 nsp 1k 1/5W nsp
R963 nsp 47k 1/5W nsp
SWITCHES
S911
9965 000 01263 SW TACT *SP000890R
S926
S927 N 9965 000 01263 SW TACT *SP000890R
S928 9965 000 01263 SW TACT *SP000890R
MISCELLANEOUS
BN72 nsp WIRE ASS’Y 7P 220 mm nsp
BN91 nsp WIRE ASS’Y 10P 200 mm nsp
BN92 nsp WIRE ASS’Y 10P 250 mm nsp
BN93 nsp WIRE ASS’Y 7P 80 mm nsp
CN71 nsp WAFER 7.92MM(YUNHO) nsp
CN93 nsp WAFER MOLEX 53014-0710 nsp
FIP1 9965 000 01465 FLD HNA-13MS08 *HQ300390R
F701 N nsp HOLDER FUSE nsp
F702 U/F nsp HOLDER FUSE nsp
OP01 nsp WIRE COPPER nsp
OP02 nsp WIRE COPPER nsp
OP03 F nsp WIRE COPPER nsp
OP04 U/F nsp WIRE COPPER nsp
C930 9965 000 01510 BACK UP CAPACITOR
0.1F 5.5V EECSOHD104V
*EX000050R
RS91 U/F nsp IR SENSOR GP1U270R *HW100420R
T701 F nsp TRANS MAINS (JAPAN)
100V 50Hz
*TS001110R
T701 N/U 9965 000 01466 TRANS MAINS
120/230V 50/60Hz
*TS001120R
X901 4822 242 10855 CRYSTAL 8.0 MHz *JX000410R
X902 4822 242 72236 CRYSTAL 32.768 kHz DT-38 XO001001T2
MAIN CIRCUIT BOARD
CAPACITORS
C101 N nsp CER. 15pF 50V J nsp
C102 N nsp CER. 15pF 50V J nsp
C103 N nsp CER. 15pF 50V J nsp
C104 nsp ELECT 10 F 35V nsp
C107 nsp CER. 0.01 F 50V Z nsp
C108 nsp CER. 15pF 50V J nsp
C109 nsp CER. 0.01 F 50V Z nsp
C110 nsp CER. 0.01 F 50V Z nsp
C111 nsp ELECT 10 F 35V nsp
C112 nsp CER. 0.01 F 50V Z nsp
C113 nsp CER. 0.01 F 50V Z nsp
C114 nsp CER. 0.01 F 50V Z nsp
C115 nsp ELECT 10 F 35V nsp
C117 nsp CER. 47pF 50V J nsp
C118 nsp CER. 15pF 50V J nsp
C120 nsp CER. 0.047 F 50V Z nsp
C121 nsp CER. 0.047 F 50V Z nsp
C122 nsp CER. 0.047 F 50V Z nsp
C123 nsp ELECT 2.2 F 50V nsp
C124 nsp CER. 0.01 F 50V Z nsp
C125 nsp ELECT 1 F 50V nsp
C126 nsp ELECT 0.47 F 50V nsp
C127 nsp CER. 0.022 F 50V Z nsp
C128 nsp ELECT 220 F 16V nsp
C131 N nsp CER. 0.01 F 50V Z nsp
C132 nsp CER. 220pF 50V K nsp
C133 N nsp CER. 100pF 50V K nsp
27
