Marcy B80 - ASSEMBLY INSTRUCTION; STEP 1

www.puretecfitness.com
6
ASSEMBLY INSTRUCTION
STEP 1
Attach the front stabilizer (2) to the front of the main frame (1), fasten with two curved
washers (16), two spring washers (73) , two allen bolts (15).
Attach the rear stabilizer (3) to the rear of the main frame (1), fasten with two curved
washers (16), two spring washers (73), two allen bolts (15).
1
15
15
73
16
73
16
2
3
