INSTALLATION DIAGRAM
FIXED INSTALLATION ON THE WALL
Locate an appropriate place on a section of the wal I as mentioned above.
Fig. 01: Front and back of the appliance.
Fig. 02: Remove screws which are xed at the front and back covers of the
appliance.
10
