Marey ECO150 - Mounting Hole Marking and Drilling

Fig. 05: Mark three mounting holes on the wall according to the following
picture, then drill three holes of 6.00mm diameter. Put expansion bolts in the
holes, and then screw the self tapping screws into the expansion bolts.
Fig. 06: Fix the appliance on the mounting screws.
12
