Mark Levinson 27.5 - Dimensions

14
Dimensions
14-3/16"
(360.2)
2-1/2"
(63.5)
12"
(304.9)
18-7/8"
(479.4)
2-1/2"
(63.5)
6-7/8"
(174.8)
5-1/4"
(133.4)
5-5/16"
(135.0)
6-11/16"
(169.7)
19"
(482.6)
1-3/4"
(44.5)
1-3/32"
(27.5)
1/2" TYP.
(12.7)
5/8"
(15.9)
15/16"
(23.8)
3/8"
(9.5)
11/16"
(17.3)
5/8"
(15.9)
7/64"
(2.8)
13/16"
(20.7)
1-1/2"
(38.1)
1-3/4" TYP.
(44.5)
1-1/4"
(31.8)
4-3/4"
(120.7)
Figure 13A: Dimensions,
Nº27.5, top view
Figure 13B: Dimensions,
Nº27.5, side view
