5.4 Fault codes.
In the event of a fault in the appliance, the message “Err” appears in the
display in combination with a digit from 1 to 8 and a fault code. The red
LED next to the info push-button will also light up.
“Err 1” means that there is a fault in appliance 1;
“Err 2” means that there is a fault in appliance 2. And so on…
The fault code indicates the type of fault. The chart below lists and
explains the possible faults.
If fault codes are active for multiple appliances, the blue info button and
the up and down button can be pressed in order to scroll through all the
codes.
Pressing the Reset push-button clears the fault code display, following which the main screen will
appear again.
Fault code chart
Code Meaning Cause
01 Ignition failure Ignition has failed (three attempts at ignition).
02 Gas valve relay/T max. Maximum thermostat is open
03 Gas valve Gas valve faulty / Wire connecting the gas valve to
the burner control box is open-circuit or has been
incorrectly connected.
22 Air compression switch The air compression switch is not open
23 Filters/system fan Filter is dirty/system fan has suffered a thermal failure
24 Air compression switch The air compression switch is not off
25 T max. Maximum thermostat is open
31 Too many attempts to restart Flame goes out (3x) when the device is in operation.
65 Phase and zero back to front Phase and zero not connected correctly
73 Ambient temperature sensor Ambient temperature sensor interrupted
76 System sensor System temperature sensor interrupted
81 Ambient temperature sensor Ambient temperature sensor has short circuited
84 System sensor System temperature sensor has short circuited
Remarks!
Please refer also to the technical documentation for the air heater for information on the above
faults, causes and solutions.
6.0 Disposal of the BaseTherm.
When the BaseTherm is replaced or removed, it must be recycled or destroyed in accordance
with national and/or local legislation and regulations.
