Mark Robin - Product Overview; Technical Details

 PRODUCT OVERVIEW

2.1 Technical details
• Certified according to EN 341:2011 class 1A (2 persons), ANSI Z359.4:2013 (1 person)
• Weight (without rope): 3,8kg
• Rope: MARK Kernmantlerope Ø9,6mm
• Descent load max. 225kg/min. 30kg (EN: 2 persons / ANSI: 1 person)
• Descent height max. 500 m
• Descent speed approx. 1,0 m/s with 85kg and approx. 1,5 m/s with 170kg
• Descent controllable by means of a rope deflection using the eye bolts
• Ambient temperature -40°C to +65°C
• The device can be used in both directions for descending and abseiling
AHK-double action
carabiner
MARK Robin
Eyebolts
MARK Robin
backside
Rope clamp
