marklin 60942 - Page 36

36
CV Table for DCC
CV
Explanation
Values
Default Notes
50
PoM
Alternative formats:
Bit 0: Analog AC off = 0 / Analog AC on = 1
Bit 1: Analog DC off = 0 / Analog DC on = 1
Bit 2: fx (MM) off = 0 / fx (MM) on = 1
Bit 3: mfx off = 0 / mfx on = 1
0 - 15
0 / 1
0 / 2
0 / 4
0 / 8
15
Note:
DCC cannot deactivate itself.
52
PoM
Motor type ... (Bit 0-4)
... Auxiliary – function outputs 5 and 6
... Motor – Softdrive Sine
... Motor – without feedback control
... Motor – high-efciency C90
... Motor – bell armature
... Motor – direct current DC soft
... Motor – direct current DC hard
... Motor – direct current DC 1 Gauge
also analog with feedback control ... (Bit 5)
... 0: with analog with feedback control
... 1: without analog feedback control
0 - 63
0
1
2
3
4
5
6
7
0
3
Selection of a motor type for additional
settings for motor feedback control
or
Selection of additional function outputs
on an H0 decoder. See extra table for how
motor outputs work as additional auxiliary
functions.
53
PoM
Motor feedback control – feedback control reference 0 - 255 150 Absolute Vmax for motor characteristic
54
PoM
Motor feedback control – feedback control parameter K 0 - 255 64 Feedback control portion P
55
PoM
Motor feedback control – feedback control parameter I 0 - 255 64 Feedback control portion I
56
PoM
Motor feedback control – feedback control inuence 0 - 255 24
0 = PWM without feedback control for
Sine (see also CV 52 motor type)
66
PoM
Forward trim 0 - 255 128
The CV value divided by 128 gives the fac-
tor with the speed level is multiplied when
the locomotive is running forward.
PoM must be supported by the locomotive controller / central controller.
