E20N Configuration – Front Panel 9
Elements on the front panel
(reference “Figure 1: E20N Front Panel” on
page 8).
A
LED Bargraph scale (20 segments) for the visualization of the sound
detected by the microphone. The color of the graduation of the scale
changes from the value of 6,5, triggering point of the command.
A1
LED to display that channel 1 has been selected.
A2
LED to display that channel 2 has been selected.
B
Programming section of GAP control (see chapter 2 “GAP control
programming” on page 10).
C
Progamming section of CRASH control (see chapter 3 “CRASH control
programming” on page 13).
Key for enabling the AGC function (automatic gain control of the sensitivity)
during the programming of the GAP control.
Key for the manual selection of channel 1 or channel 2.
