CV620-IP / CV620-IPW
31 User Manual v.1
7.3.5 Settings –Advanced Video Setting
1. IP Ratio: Set IP Ratio, from 1 to 60
2. Force I Frame :
Check this item to insert IDR frame into specified series flow and apply its setting. User’s setting
will be reserved and displayed in GUI interface
3. Encode Preset :
Auto: Select between speed and quality depending on the encoding method used (e.g.
HIGH_SPEED mode for refresh rate of 60 frames per second and HIGH_QUALITY mode for
high image quality)
HIGH_SPEED: Refresh rate of 60 frames per second is available
HIGH_QUALITY: Higher image quality can be obtained.
SVC: SVC opened encoding mode is applicable to RTSP series flow of 8601, 8602, 8603 and 8604
ports, different refresh rate for different ports. See remark
4. Encode Profile: Encoded Information
5. Preset Save
Note: SVC connection address: rtsp://VC IP Address:Port/h264
1. 60Frame : rtsp://VC IP Address:8557/h264, E.g.: rtsp://192.168.100.150:8557/h264
2. 30Frame : rtsp://VC IP Address:8601/h264, E.g.: rtsp://192.168.100.150:8601/h264
3. 15Frame : rtsp://VC IP Address:8602/h264, E.g.: rtsp://192.168.100.150:8602/h264
4. 7Frame : rtsp://VC IP Address:8603/h264, E.g.: rtsp://192.168.100.150:8603/h264
5. 3Frame : rtsp://VC IP Address:8604/h264, E.g.: rtsp://192.168.100.150:8604/h264
