Marshall Amplification CV620-IP User Manual

CV620-IP / CV620-IPW
18 User Manual v.1
Chapter 5. Remote Control and Setting Menu
5.1 Functions of remote control
Note: The below functions are listed alphabetically.
Item Description

,

,

,

Move the lens
Back Light Turn on/off back light compensation
Camera
select
Choose 1 ~ 3 of CV620-IPW
Focus-
Manual /
Far/Near
Turn on manual focus to adjust the focal
length
Focus-Auto Auto focus
Freeze Freeze the screen
Home-Enter Go back to the main page / Execute
Info Status information
L/R
Direction Set
L/R Direction / Normal
Menu Display OSD menu
Mirror Rotate the image (OFF / Mirror / Flip /
Rotate)
Pan/Tilt
Reset
Clear the Pan / Tilt setting
Picture Switch image effect (OFF / NEG / Black &
White)
Power Power Switch
Preset Appoint an ID (0 ~ 9) to save the current
position data
Reset Appoint an ID (0 ~ 9) to delete the current
position data
Zoom-Fast Adjust image size
Zoom-Slow Fine-tune image size
