Marshall Amplification CV620-IP User Manual

CV620-IP / CV620-IPW
17 User Manual v.1
Note: With RS-422, at most 7 VCs can be connected.
4.3.3 Use of CV620-IPW with Internet Connection
4.3.3.1 Setup before use
 Connecting the screen through HDMI output.
 Press [MENU] on the Remote Control to display the OSD menu.
 Shift down to [Ethernet] to modify and confirm the IP address
DHCP: Enable/disable the dynamic host configuration protocol
IP Address: Confirm or modify the IP address of CV620-IPW
Subnet mask: 255.255.255.0
Gateway: Preset 192.168.100.254
[Remark] Please modify the above settings based on the LAN setting of the operating environment. To use
DHCP, please connect the CV620-IPW to LAN and then confirm IP address.
 After completing settings, press [MENU] to exit the OSD menu.
 After completing setting and confirming IP address, HDMI cable can be disconnected.
4.3.3.2 Start Using
 Connect network cable to CV620-IPW network port to connect CV620-IPW to LAN.
 Press [MENU] on the Remote Control to display the OSD menu.
 Open the browser, and enter the URL of CV620-IPW in the address bar,
e.g.: http://192.168.100.150 (default IP address)
 Enter administrator’s account and password
Account: admin (Default)
Password: 9999 (Default)
Subnet mask: 255.255.255.0
Gateway: Preset 192.168.100.254
[Remark 1] For details, please refer to Chapter 7 Network Function Settings Description.
[Remark 2] In addition to browsers, other software such as VLC and QuickTime can be used for operation.
