CV620-IP / CV620-IPW
16 User Manual v.1
4.3.1.4 Connecting AUDIO IN
Note: Set the [Audio In] in the OSD to reflect the input device
4.3.2 Controlling VCs with the computer
4.3.2.1 Connecting to one computer for connection between VCs (RS-232 in/out)
Note: With RS-232 in/out, at most 7 VCs can be connected.
4.3.2.2
Connecting to one computer for connection between VCs (RS-422)
Note: Please refer to 8.2 RS-422 connection for the RS-422 connection instructions.
MIC or audio mixer
Audio
