030
031
TECHNICAL INFORMATION
ACOUSTIC SPECIFICATION
• CABINET PRINCIPLE: Enclosed
• DIGITAL CLASS D AMPLIFIERS: 30 W
• BASS AND TREBLE TONE CONTROLS
• FREQUENCY RESPONSE: 54-20,000 Hz ±6 dB
• MAXIMUM SOUND PRESSURE LEVEL:
96 dB SPL @ 1 m
TECHNICAL SPECIFICATION
• MAINS INPUT VOLTAGE: 100–240 VAC
• MAINS FREQUENCY: 50/60 Hz
• NETWORK STANDBY POWER CONSUMPTION:
<2 W
• WIRELESS CONNECTIVITY:
– Spotify Connect
– AirPlay 2
– Bluetooth
• WI-FI SUPPORT: Connects to your home Wi-Fi
network with any WPA, 802.11b/g/n/ac 2.4
GHz/5 GHz with diversity.
• SIZE: 128 x 168 x 123 mm
• WEIGHT: 1.39 Kg
• VOICE CONTROL SERVICE: Amazon Alexa
• MICROPHONE SYSTEM: A dual microphone array
with acoustic noise cancellation for far field voice
interaction.
TROUBLESHOOTING
PROBLEM CAUSE ACTION
THE UXBRIDGE DOES NOT
TURN ON
The speaker is not connected to
mains electricity supply.
Connect the mains lead to the
Uxbridge and a working wall
socket.
THE UXBRIDGE CANNOT BE
DISCOVERED BY THE MARSHALL
VOICE APP
The speaker is not in setup mode. Push and hold the play/pause
button for 7 seconds to set the
speaker in discoverable mode.
The speaker and the mobile
device are not connected to the
same Wi-Fi network.
Ensure that your mobile device
is connected to the same Wi-Fi
network that the speaker was
configured for.
ALEXA IS NOT RESPONDING The microphone is muted on the
speaker.
Push and hold the microphone
button for 2 seconds. The LED
indicators on the front turn o to
indicate that the microphone is
unmuted.
THERE IS NO AUDIO OR AUDIO
IS TOO LOW
Your audio device is not
connected to the speaker.
Ensure that the device is
connected to the Uxbridge.
Volume is set too low on either the
audio source or the speaker.
Slightly increase the volume on
your audio source or the speaker.
Note: The front of the speaker is not
removable. This illustration intends to show
the internal speaker layout. Do not attempt
to remove the fret for risk of damaging
your speaker.
