VS-102-HDSDI User Manual
IP Server Instruction Manual
36/61
 Serial Port Type and Configuration
 Serial Port type: There are two serial ports, RS-232, RS-422/485 in VS-102-HDSDI.
Select RS-422 or RS-485 in the RS-422/485 port.
 Serial Port Configuration: The serial ports can be configured as follows:
Each of the serial ports configurations must be same as the connecting device.
Mode
Selection
Bitrate
2400, 4800, 9600, 19200, 38400, 57600,
115200 bps
Data Bits
5, 6, 7, 8 bits
Parity
NONE, EVEN, ODD bit
Stop Bit
1, 2 bit
 PTZ
 PTZ Type: Select the type of PTZ camera or receiver.
 PTZ ID: Since it is possible to control multiple PTZ cameras or receivers over single control line,
each camera or receiver will be assigned with a unique ID. Enter the PTZ ID of a camera or receiver
for control. The ID value range can be between 0 and 255.
 PTZ Port: Select the serial port used for PTZ camera control.
 Direct Keyboard Control: Keyboard controller can be connected to VS-102-HDSDI directly to
the control zoom and focus.
 Sensor Type
There are two sensor input ports on the VS-102-HDSDI. Each of the sensor ports can be configured
as follows:
Function
Operation
OFF
Not used
NO (Normally
Open)
The port is normally open and activated when
closed.
NC (Normally
Closed)
The port is normally closed and activated
when opened.
The function of the sensor port is set based on the type of the sensor connected.
 Sensor Schedule
Each sensor port can be enabled or disabled by a day (of week) and hour unit. Sensor is
disabled for grey-colored block.
