Appendix
1. Appendix A : Sensor and Alarm Port
 Sensor Port
 Terminal Type
- Voltage Rating: 150VAC
- Current Rating : 2A
- Color : Red
 Sensor Signal Input Type
- NO Contact Signals
 Connection to External Device
