7)
(2 messages flashing)
Signal from CTs insufficient for automatic phase sensing, proceed to manual
setup routine
6)
(2 messages flashing)
Non specific connection error
e-Tracker portable energy monitor operating and maintenance manual
9
--
ID ERR 3
--
MTH-DAY HRS-MINS
2011 07.14 10.40
--
NOT FOUND
--
MTH-DAY HRS-MINS
2011 07.14 10.40
LO indicates which channel(s) has insufficient signal.
Increase phase current if possible, switch off, switch on (after 5 seconds) and try again.
Manual set up routine
Switch off e-Tracker, plug in EV-Trac probe and switch on after 5 seconds.
The SELF TEST routine starts.
PROBE SCAN
MTH-
NO SIGNAL
2011
07.14 10.40
Followed by:
Place the Probe along the phase cables’ insulation one at a time. Display indicates L1
or L2 or L3, clip-on the appropriate CT as below.
• Red CT on phase indicated as L1 (ignore phase cable colour)
• Yellow CT on phase indicated as L2
• Blue CT on phase indicated as L3.
If 'SIG ERR' displayed move Probe to different location on cable, away from other
phase cables.
Press enter
LO INPUT
MTH-
LO LO LO
2011
07.14 10.40
USE PROBE
MTH
LO LO LO
2012011
07.14 10.40
