Marshall-Tufflex e-Tracker - Error Messages

5)
(2 messages flashing)
CTs wrong way round or CTs not in l1 connector when used on single phase
4)
(2 messages flashing)
Two CT connected to same phase
e-Tracker portable energy monitor operating and maintenance manual
8
Error messages
After switch on and during the set up the display will indicate an unacceptable connection.
Check CTs and voltage reference input (if used), correct any error, press ENTER and
proceed with set-up.
1)
(3 messages flashing)
No CTs connected
--
ERROR
--
TRANSDUCER
--
NO CT
--
MTH-DAY HRS-MINS
2011 07.14 10.40
--
ERROR
--
MTH-DAY HRS-MINS
2011 07.14 10.40
TRANSDUCER
MTH-DAY HRS-MINS
2011 07.14 10.40
--
CT1-2-3 ODD
--
MTH-DAY HRS-MINS
2011 07.14 10.40
2)
(3 messages flashing)
CTs have different full scale current ratings or only two are connected
--
ERROR
--
MTH-DAY HRS-MINS
2011 07.14 10.40
TRANSDUCER
MTH-DAY HRS-MINS
2011 07.14 10.40
VOLTS
--
CT ODD
--
MTH-DAY HRS-MINS
2011 07.14 10.40
3)
(3 messages flashing)
If three phase volt probes connected but only one CT connected VOLTS CT ODD
--
ID ERR 1
--
MTH-DAY HRS-MINS
2011 07.14 10.40
--
NOT 3 PHASE
--
MTH-DAY HRS-MINS
2011 07.14 10.40
--
ID ERR 2
--
MTH-DAY HRS-MINS
2011 07.14 10.40
--
CTS ODD
--
MTH-DAY HRS-MINS
2011 07.14 10.40
