MX-1 user manual DIP-switch settings 13
SPECIAL SETTINGS
The DIP-switch is used to select special personality options when the fixture is
operated in stand-alone and master/slave mode.
Lamp life can be extended beyond the stated average hours by reducing the lamp
voltage slightly. Set DIP-switch pin 12 to ON for longer lamp life, or OFF for full
output intensity.
Important! Pin 10 must be ON to enable special settings on pins 1 - 9.
Pin Setting Effect
1
ON Music trigger
OFF Automatic trigger
2
ON Stand-alone “master” fixture
OFF Stand-alone “slave” fixture
3 ON/OFF Reserved, no effect
4
ON Slow mirror movement (set on master fixture)
OFF Fast mirror movement
5
ON Wide mirror movement (set on master fixture)
OFF Narrow mirror movement
6
ON Random effect wheel position (set on slave fixture)
OFF Effect wheel position same as master
7
ON Inverted effect wheel position (set on slave fixture)
OFF Normal effect wheel position
8
ON Inverted tilt (set on slave fixture)
OFF Normal tilt
9
ON Inverted pan (set on slave fixture)
OFF Normal pan
10
ON Enable special settings with pins 1 - 9
OFF Enable DMX address with pins 1 - 9
11
ON 1-channel mode on
OFF 1-channel mode off
12
ON Reduced power / longer lamp life
OFF Full power / maximum intensity
