MX-1 user manual Operation 17
The single-channel controllable functions are shown below.
STAND-ALONE OPERATION
The MX-1 automatically begins to operate in stand-alone mode with music
trigger - regardless of the DIP-switch settings - if there is no control signal.
The operation of single and “slave” units can be modified using the special DIP-
switch settings as described under “Special settings” on page 13.
MASTER / SLAVE OPERATION
Multiple MX-1s can be connected together for synchronized “master/slave”
operation in which the slaves mimic the behavior of the master.
In order to operate in this mode, the MX-1s must be connected together. One
fixture must be selected to be the master (DIP-switch 2 ON) and the others must
be set as slaves (DIP-switch 2 OFF).
Important! Only 1 fixture can be the master: errors and damage can occur
if there is more than 1 control signal on the data link.
To connect units for master / slave operation
1 Connect the output of one MX-1 to the input of the next MX-1.
2 Connect additional MX-1s output to input. Up to 32 may be connected.
3 Terminate the link on both ends by inserting a female termination plug into
the data input of the first fixture and a male termination plug into the data
output of the last fixture. A termination plug is simply an XLR connector with
a 120 ohm, 0.25 W resistor soldered across pins 2 and 3.
DMX value Percent Function
0 - 10
11 - 20
21 - 80
81 - 115
116 - 140
141 - 175
176 - 210
211 - 255
0 - 4
5 - 7
8 - 31
32 - 45
46 - 55
56 - 68
69 - 82
83 - 100
Blackout (light off)
Open (light on)
Strobe
Random action with slow music trigger
Random action with medium music trigger
Random action with fast music trigger
Random action with random music trigger
Manual trigger area, crossover at 240 (94%)
