13
FIREPLACE COMPONENTS
SF42A
SF42AI
SCF42A
SCF42AI
S48
S36
S18
S12
SE30
SCS
SC
SCL
SQL8
612
1212
SF
SF-30
FP-4-U
403
AK4
GD42PB
GD42B
FA2
H2066
JB1
S8
CF8
MODEL
30-degree elbows (package contains two 8-inch diameter elbows.)
Chimney support (required when chimney height exceeds 30 feet)
Round chimney cap for contemporary installation, includes storm collar
Round telescoping chimney cap
Square telescoping chimney cap (18 1/2" x 18 1/2")
0-6/12 pitch flashing for contemporary installation. One required with SC round chimney cap on 0-6/12 pitch roof.
6/12-12/12 pitch flashing for contemporary installation. One required with SC round chimney cap on 6/12-12/12
pitch roof.
14-1/2-inch firestop spacer - One required at each ceiling or floor level
Firestop spacer - 30" chimney incline through ceiling or floor
4-inch uninsulated combustion air duct - 8-foot length
4-inch duct connector (for splicing FP-4-U ducts, includes one connector and two clamps)
4-inch outside combustion air assembly
Optional 42-inch polished brass glass door kit
Optional 42-inch black finish glass door kit
Optional fan assembly - includes switch. Installs under fireplace by removing lower grille panel of fireplace.
(SCF42A & SCF42AI)
Hearth extension - protects floor against sparks and radiant heat (Residential installation) 20" x 66"
Junction box - For Optional Blower Assembly Installation. Must be installed at the time of fireplace installation if the
model FA2 Fan is to be installed.
Telescope assembly for use with telescoping chimney caps.
Terra cotta chimney cap (Must use with VFK)
42-inch non-circulating fireplace
42-inch insulated non-circulating fireplace with insulating outer wraps.
42-inch circulating fireplace
42-inch insulated circulating fireplace with insulating outer wraps.
4-foot chimney section (8-inch diameter flue)
3-foot chimney section (8-inch diameter flue)
18-inch chimney section (8-inch diameter flue)
1-foot chimney section (8-inch diameter flue)
DESCRIPTION
53D9022. Rev 1 03/03
