REPAIR PART DIAGRAMS AND LISTS
All repair part orders should be placed through your local dealer. To ensure prompt and accurate service,
please provide the following information when placing a repair part order: Model number of your Appliance,
Part Name, Part Number, and Quantity of parts needed.
PART NUMBER
077072
031867
070874
034820
035493
077068
035326
QTY.
1
1
2
1
2
1
1
1
KEY NO.
1
2
3
4
5
6
7
8
PART NAME
UPPER PANEL PNTD. ASSY.
WELDMENT AIR DOOR ROD
FIRESCREEN PANELS
FIREBRICK BACK ASSY.
FIREBRICK SIDE ASSY.
LOWER PANEL PNTD. ASSY.
GRATE PNTD. ASSY.
HEARTH REFRACTORY ASSY.
035018
SF42A / SF42AI
MODEL FIREPLACE
Technical Service Department
2813 W. Mall Drive, Unit B.
Florence, Alabama 35630.
Tel. - 1-866-500-5671
www.martinhearthandheating.com
53D9022. Rev 1 03/03
