21
Dimensions and Range of Motion - Light Head
Service Location - Track Light Power Supply
120° 120°
40°
140°
Transformer Cover
6-32 Phillips Head
Screw
Transformer
Insulator
Transformer
Fuses
Ground
Location
Power
Switch
