Marus TL 500 - Suspended Ceiling Mounting; Suspended Ceiling Installation Details

7
Suggestions for Suspended Ceiling
BE SURE TO BRACE
STRUCTURE IN BOTH
DIRECTIONS
MINIMUM SIZE 3/4”
PLYWOOD PANEL
77-5/8” x 10” WIDE
CEILING JOISTS
16” ON CENTER
LAG BOLTS (NOT INCLUDED)
LONG ENOUGH TO GO AT LEAST
3/4” INTO PLYWOOD PANEL
PRE-ASSEMBLED
FROM FACTORY
