− US-10 −
Installing Trimmer Head
WARNING
POTENTIAL HAZARD
•
If the Trimmer Head is not adequately
tightened, it can come loose from the String
Trimmer during use.
WHAT CAN HAPPEN
•
This may cause damage to property or
personal injury.
HOW TO AVOID THE HAZARD
•
Make sure the trimmer head is securely
fastened to the attaching shaft in the
gearcase.
IMPORTANT: The boss adapter must be, installed
on the attaching shaft between the gearcase and the
trimmer head as shown. And attaching shaft is left-
head threaded.
1. Install the boss adapter onto the attaching shaft
out of the gearcase.
2. Align the hole in the boss adapter with the hole in
the gearcase.
3. Insert the 3.5 mm pin into the holes in the boss
adapter and gearcase to lock the attaching shaft.
4. Thread the attaching shaft into the trimmer head
adapter, then tighten the trimmer head firmly by
hand.
5. Remove the 3.5mm pin from the boss adapter and
gearcase.
Before Operation
Oil and Fuel
DANGER
POTENTIAL HAZARD
•
In certain conditions gasoline is extremely
flammable and highly explosive.
WHAT CAN HAPPEN
•
A fire or explosion from gasoline can burn
you, others and cause property damage.
HOW TO AVOID THE HAZARD
•
Use a funnel and fill the fuel tank outdoors,
in an open area, when the engine is cold.
Wipe up any gasoline that spills.
•
Do not fill the fuel tank completely full. Add
gasoline to the fuel tank until the level is 1/4”
to 1/2” ( 6 mm to 13mm ) below the bottom
of the filler neck. This empty space in the
tank allows gasoline to expand.
•
Never smoke when handling gasoline, and
stay away from an open flame or where
gasoline fume may be ignited by a spark.
•
Store gasoline in an approved container and
keep it out of the reach of children.
•
Never buy more than a 30-day supply of
gasoline.
1. Do not smoke near fuel.
2. Mix and pour fuel outdoors and where there are
no sparks or flames.
WARNING
POTENTIAL HAZARD
•
Gasoline contains gasses that can build up
pressure inside a gas tank.
WHAT CAN HAPPEN
•
Fuel can be sprayed on you when removing
gas cap.
HOW TO AVOID THE HAZARD
•
Remove fuel cap slowly to avoid injury from
fuel spray.
