grado di garantire l’accoppiamento degli steli
con la base di sterzo.
Nelle forcelle con tubi portanti fissati a vite
sulla base di sterzo e archetto di irrigidimento
amovibile dai foderi, è necessario, prima del
montaggio sul telaio, controllare il serraggio
delle viti di fissaggio (Rif. 2 e 3).
La distanza “H” tra la base di sterzo e l’estre-
mità del pneumatico (gonfio) non deve essere
inferiore alla corsa totale T+3 mm.
A
TTENZIONE: un posizionamento diverso della
base rispetto ai tubi portanti può causare
il contatto tra pneumatico e base di sterzo e
procurare gravi danni al ciclista.
MONTAGGIO FORCELLE DOPPIA PIASTRA SU TELAIO
Procedete al montaggio della forcella sul tela-
io, già provvisto di serie di sterzo.
Installate la piastra superiore (Rif. 4) nei tubi
portanti e nel cannotto.
L’estremità dei tubi portanti deve risultare a
filo o leggermente più bassa della piastra supe-
riore.
In caso di eccessiva sporgenza degli steli,
spessorate, con distanziali (Rif. 5), la piastra
in corrispondenza del cannotto di sterzo.
Installate sopra alla piastra superiore il sup-
porto manubrio e il tappo A-Head Set, quindi
registrate lo sterzo.
A questo punto bloccate definitivamente le viti
(Rif. 6) sulla piastra superiore.
Se per qualche motivo avete modificato la
posizione della base di sterzo rispetto ai tubi
portanti è necessario ristabilire la distanza
originale (H)
Serrare le viti (Rif. 2) di fissaggio dei tubi
portanti alla base di sterzo alla coppia pre-
scritta.
A
TTENZIONE: un serraggio eccessivo delle viti
di fissaggio tubi portanti alla base di sterzo
può deformare i tubi ed indebolire la struttura.
the bolts (ref. 2) have become loose.
Where the fork stanchions are bolted onto the
crown and the stiffening arch can be removed
from the sliders, check the tightening torque of
the bolts (ref. 2 and 3) before installing the
fork to the frame.
Distance “H” between crown and tyre edge
(when inflated) should not be lower than total
travel T + 3 mm.
W
ARNING: if steering crown is improperly
matched with stanchions, it may touch the
tyre and cause severe injuries to the rider.
MOUNTING THE DOUBLE-PLATE FORKS ON THE FRAME
Assemble the fork to the frame complete with
headset.
Fit the upper plate (ref. 4) into the upper
stanchions and the steer tube.
The stanchions edge must be aligned with or
slightly lower than the upper plate.
If fork legs overprotrude, fit some spacers (ref.
5) to the plate close to the steer tube.
Fit the handlebar support and the A-Head Set
cap over the upper plate and then adjust the
steering.
Now finally tighten the screws (ref. 6) on the
upper plate.
If the crown position with respect to the stan-
chion tubes has been changed for any reason,
adjust the original distance (H).
Tighten the bolts (ref. 2) holding the stanchion
tubes to the crown to the specified torque.
W
ARNING: do not overtighten the screws
holding the stanchions to the crown as this
may distort the stanchion tubes and weaken the
whole structure.
