Marzocchi MARATHON - REMOVING GUIDE BUSHING AND SEAL ASSEMBLY

M
A
R
A
T
H
O
N
10
9
8
A
REMOVING GUIDE BUSHING
AND SEAL ASSEMBLY
FIG. 10
Remove the dust seal (10) from the top of
the sliders using a small screwdriver.
FIG. 11
Remove the stop ring (9) from the sliders by
placing the screwdriver bit in one of the
three openings on the stop ring.
IMPORTANT: when removing the stop
ring, make sure not to damage slider inner
seat.
FIG. 12
Fit the slider protector (A) onto the slider
and remove the oil seal (8) with the help of
a large screwdriver.
IMPORTANT: when removing the oil seal,
make sure not to damage slider inner seat.
Once removed the oil seals should not be
used again.
