8 Technical Specifications
8.1 General Specifications
Description Compact, battery powered, quantitative capnograph for mainstream
CO
2
monitoring of adult, pediatric and infant patients.
Measurements Non-dispersive IR absorption
Models CO
2
displayed in kPa or mmHg
Warm up In operation and full accuracy within 15 s.
Calibration No routine calibration required
Certifications CE marked per 93/42/EEC, FDA 510(k) and UL/CSA 60601-1
Dimensions 52 x 39 x 39 mm (2.1 x 1.5 x 1.5 inches)
Weight ~60 g (2.1 oz) with batteries
Mechanical robustness Withstands repeated 1 m drops.
Meets the shock and vibration requirements for transport of SS-EN ISO
21647:2004 clause 21.102 and SS-EN 1789:2007 clause 6.3.4.2.
Operating conditions Temperature: -5 - +50°C (23 to 122°F)
Humidity: < 40 hPa H
2
O (non-condensing) (95% RH at 30 °C)
Atmospheric pressure: 70 - 120 kPa
(1)
Storage conditions Temperature: -30 - +70°C (-22 to 158°F)
Humidity: 5 - 100% RH (condensing) at a water vapor partial pressure
not exceeding 74 hPa (100 %RH at 40 °C)
Atmospheric pressure: 50 - 120 kPa
Display 96 x 96 pixel RGB OLED-display
ETCO
2
0 - 99 mmHg (0 - 9.9 kPa)
(2)
CO
2
Accuracy 0-40 mmHg ± 2 mmHg, 41-99 mmHg 6% of reading, during standard
conditions.
(3) (4)
Total system response time < 0.5 s
Recovery time after
defibrillator test
Unaffected
Respiratory rate 3 - 150 breaths/min
Accuracy ± 1 bpm
Breath detect Adaptive threshold, minimum 1 kPa CO2 change
Adult/Pediatric Dead space 6 ml, Flow resistance < 0,3 cm H2O (@ 30 LPM)
Infant Dead space 1 ml, Flow resistance < 1,3 cm H2O (@ 10 LPM)
Alarms No Adapter, Clogged Adapter, No Breath Detected, Low Battery, Low
ETCO2, High ETCO2
Sound Intensity Level ≥ 80 dB(A)
Batteries Two AAA Cell batteries (2x1.5VDC):
Alkaline IEC:LR03 or
Energizer Ultimate Lithium L92 batteries
(5)
. Use of other Lithium
batteries may present a risk of fire or explosion.
