AUSTRALIA
MINIMUM DISTANCES TO HEAT SENSITIVE WALLS (mm)
‡
WITH THE APPROPRIATE FLUE HEAT SHIELD
Model
A B C D E F R §
Horizon 150* 350 320* 628 100 405 575
LE 2000 125 325 295 603 100 405 575
Siena (with flue shield) 150 250 320 528 100 405 575
Siena (without flue shield) 360 250 530 528 230 535 760
LE 3000 Series 2 150* 325 375* 655 125 480 680
LE 5000 Series 2 150* 325 375* 655 125 480 680
Verona 250† 300 470† 630 125 480 680
Toronto 125 350 320 680 100 475 675
Panorama Series 3 150* 350 375* 680 125 455 645
Grandview 150 350 345 730 100 508 720
* May be reduced by 25mm if a polished stainless steel flue shield is fitted instead of an enamelled one.
May be reduced by 50mm if a polished stainless steel flue shield is fitted instead of an enamelled one.
† May be reduced by 125mm if a polished stainless steel flue shield is fitted instead of an enamelled one.
§ Valid only when the room walls are at 90° to each other.
‡ Note: Clearances are for fire hazard only. For durability of finishes or surfaces you should contact the
relevant manufacturer for their specification. MASPORT accepts no responsibility for the deterioration of
surfaces or finishes.
TESTED 150mm FLUE OPTIONS:- (For all models except Toronto and Grandview)
Acorn Metal - Special Insulated Flue Kit with 900mm 120˚ polished reflector.
Benja Pty Ltd - Benja Mk II with 900mm decorative heat shield with 120˚ solid back. (Not
tested on Verona)
Floate Metal - Flomet Super Single with full length decorative heat shield with 120˚ solid back.
Shamic Sheetmetal - Model 1A with full length decorative heat shield with 180˚ solid back.
(Not tested on Verona and Panorama)
Statewide Heating - Model M1 with 900mm half-round enamelled flue shield.
Woodland Fireplaces - Woodland Double Flue System with flat ceiling plate and 900mm
180˚ stainless steel heat shield. For LE3000 Series 2, LE 5000 Series 2,
Verona and Panorama Series 2 only.
TESTED 178mm (7”) FLUE OPTIONS:- (For Toronto and Grandview models)
Acorn Metal - Special Insulated Flue Kit with 900mm long half-round enamelled mild steel
or polished stainless steel flue shield.
Floate Metal - Flomet 7” Super Single flue system with full length perforated decorative heat
shield with 120˚ solid back. The ceiling plate has a 200mm diameter collar extending down
100mm surrounding the decorative shield.
Statewide Heating - Standard 7” Flue Kit with 900mm long half round polished stainless steel
flue shield. (Not tested with Toronto)
OTHER FLUE SYSTEMS
Flues and flue heat shields other than those listed above may be used, but if they have not been
tested with these heaters, their installation clearances will be those specified in AS/NZS
2918:2001 for untested flue installations.
