SPECIFICATIONS
MODEL 500UTV 500LUTV
Dimensions:
Overall length 2600 mm (102.4in) 3345 mm(131.7in)
Overall width 1280mm (50.4in) 1290mm(50.8in)
Overall height 1960mm (77.2in) 1865mm(73.4in)
Seat height 870mm (34.3in) 830mm(32.7in)
Wheelbase 1760mm （69.3in） 2450mm(96.5in)
Minimum ground clearance 210mm （8.3in）
Minimum turning radius 4200mm (165.4in) 4900mm(192.9in)
Maximum speed 80 km/h
Basic weight:
Mass of whole equipments (Not include
driver)
590kg 635kg
Engine:
Engine type Water-cooled 4-stroke, CF188
Cylinder arrangement single cylinder
Displacement 493 CC
Bore × stroke 87.5×82.0 mm (3.4×3.2 in)
Compression ratio 10.2:1
