Massimo MSU 800-5 - Wheel Installation

- 101 -
Wheel installation
1. Install the wheel and nuts.
NOTE:
●
The arrow mark on the tire must point
the direction toward the wheel turns.
●
Tapered nuts are used for both the front
and rear wheels. Install the nut with its
tapered side towards the wheel.
1. Arrow mark
1. Tapered nut
2. Lower the vehicle so that the wheel
is on the ground.
3.Tighten the wheel nuts to the
specified torque.
Wheel nut to Rear: torque:
Front & Rear:
64 Nm (6.4 m.kgf, 47 ft.lbf)
