4. Technical index
DIGITAL CLAMP METER DIGITAL CLAMP METER
4.1 General index
• Environmental conditions for using:
Temperature and relative humidity of working
environment: 0~40 ˚C (<80%RH).
• Temperature and relative humidity of storage
environment: -10~60 ˚C (<70%RH, removing battery).
• Maximum voltage between any input socket
and earth: 600Vrms.
• Principle of measurement: double integral A/D
conversion.
• Sampling rate: about 2 times/second.
• Display: 3 1/2 digits LCD display with max.
reading 1999.
• Automatically indicate unit and symbol according to
function level.
• Measuring range switch method: manually
• Over measuring range indication: “OL” will display on
LCD. When the input measuring voltage exceeds
2000V, “OL” will display on the LCD (ACV and DCV).
• Input polarity indication: “–” symbol will display
automatically.
• Low battery indication: When the low battery is lower
than the normal operating voltage,“ ”will display on
the LCD.
• Battery: DC 1.5V X 2 SIZE AAA
• Max. opening dimension of transformer jaws: φ28mm.
• Max. dimension of conductor: φ28mm.
• Dimension: 194(L)×72(W)×35(H)mm.
• Weight: about 200g (with battery).
• Accessories: Instruction Manual, leads, package bag
and package box.
MARK
CONDUCTOR
MARK
MARK
4.2Accuracy index
Accuracy: ±( % reading + the number of characters),
gurantee for one year.
Base condition: ambient temperature is from
18˚C to 28˚C, relative humidity is not greater than 80%
• When making AC current measurement, please position
the conductor to the center If the conductor is not
positioned at the center, the max. additional error
resulted is 1.5%.
