Mastech MS2301 User Manual

6
Current
10.0mA -99.0mA
0.1mA
±（2.5%＋5mA）
100mA -300mA
1mA
±（2.5%＋10mA）
0.30A-2.99A
0.01A
±（2.5%＋0.1A）
3.0A-9.9A
0.1A
±（2.5%＋0.3A）
10.0A-20.0A
0.1 A
±（2.5%＋0.5A）
Ⅴ . Technical Specifications
Functions
Ground resistance test, Loop resistance test
Ambient Temperature
and Humidity
23℃±5℃，below 75%rh
Power Supply
DC 6V （4 AA alkaline dry batteries）
Range
Resistance: 0.01-1200Ω
Current：0.00mA-20.0A
Measure Method
Mutual induction
Resistance Resolution
0.001Ω
Jaw Size
55mm×32mm
Clock Function
Have
Display Mode
4-digit LCD display, black screen design
LCD Size
46mm×29mm
Meter Size
L/W/H：285mm×85mm×58mm
Measure Time
2times/second
Data Storage
300 groups，"MEM" storage indication, display "FULL"
symbol indicates that storage is full
Data Review
"MR" symbol indicates when looking up data
Overflow display
"OL" symbol indicates over-range overflow
