Mastech MY67 - 4.6 Resistance Specifications; 4.7 Capacitance Specifications; 4.8 Frequency Specifications

Overload protection: F 500mA fuse for µA and mA
ranges, F 10 A fuse for A range.
Frequency Range: 40Hz to 400Hz
Response: Average, calibrated in rms of sine wave
4.6 RESISTANCE
Range Resolution Accuracy
400Ω 0. 1Ω ± 0.8% of rdg ± 3 digits
4KΩ 1Ω ± 0.8% of rdg ± 1 digits
40KΩ 10Ω ± 0.8% of rdg ± 1 digits
400KΩ 100Ω ± 0.8% of rdg ± 1 digits
2MΩ 1KΩ ± 0.8% of rdg ± 1 digits
40MΩ 10KΩ ± 1.2% of rdg ± 2 digits
Max. open circuit voltage: 3.2V
4.7 CAPACITANCE
Range Resolution Accuracy
4nF 1pF
40nF 10pF
400nF 100pF
4µF 1nF
40µF 10nF
200µF 100nF
± 3.0% ± 20
4.8 FREQUENCY
Range Resolution Accuracy
100kHz 1Hz ± 2 % ± 5
-
12
-
