Step 5
Step 6
A
1 Pc
B 1 Pc
C 1 Pc
10
Model No. 085-3179 | Contact us: 1-855-803-9313
Assembly Instructions
5
A
5
B
C
Attach regulator hose hook (5) using short screws (A) one washer (B) and one nut (C) as shown below.
Inserting and Securing LP Gas Tank.
so the tank valve is facing the gas line connection as shown below.
WARNING: Never put or lay down the LP Gas Tank underneath the BBQ as shown below, which may result in
an explosion, fire, severe personal injury or death.
To Next Page
