17
CARE AND MAINTENANCE
BURNER ASSEMBLY
REMOVING THE BURNER ASSEMBLY
1. Make sure all control knobs are in the OFF
position, LP tank valve is closed, and tank
is disconnected from regulator and removed
from grill.
2. Open lid and remove warming rack, cooking
grates, and heat tents.
3. Remove cotter pins at back of burners to detach burners from brackets.
6OLGHEXUQHUVRXWRIILUHER[DVVKRZQ
Warming Rack
Cooking Grates
Heat Tents
5. Detach ignition wire from ignitor as shown.
Burner
Bracket
Cotter Pin
Burner
To Next Page
