4. Insert 2 screws (AA) halfway into the top
front threaded holes of both the cart left side
panel (D) and the cart right side panel (E).
Attach the upper front door brace (G) by
sliding the cut-outs in the front door brace (G)
over the 4 screws (AA) and tightening all 4
screws (AA).
4
Hardware Used
AA
[
0[6FUHZ
E
AA
D
G
AA
G
ASSEMBLY INSTRUCTIONS
8
3. Insert one screw (AA) halfway into the middle
rear threaded hole of each of the cart left side
panel (D) and cart right side panel (E). Attach
the cart rear panel (F) by sliding the keyholes
in the cart rear panel (F) over the inserted
screws. Slide the rear cart panel (F) down to
meet bottom shelf (A). Secure the cart rear
panel (F) to the bottom shelf (A) with 2 screws
(AA). Tighten all screws, including the 4
screws in cart side panels (D and E).
AA
F
3
E
D
A
Hardware Used
AA
[
0[6FUHZ
To Next Page
