Master Forge MFJ576PNC - Grates and Warming Rack Installation

14
ASSEMBLY INSTRUCTIONS
Lowes.com/masterforge
27
II
C
Z
1
1
2
26
C
II
25
Y
C
3ODFHIRXUJUDWHV<RQOLGDQG¿UHER[
assembly (C).
26. Attach one M6x30 bolt (II) on each side of lid
DQG¿UHER[DVVHPEO\&'2127IXOO\WLJKWHQ
27. Insert one end of warming rack (Z) onto M6x30
EROW,,DQGLQWRWKHKROHRQOLGDQG¿UHER[
assembly (C). Repeat for other side.
Hardware Used
M6x30 Bolt
x 2
II
