Master Forge MFJ576PNC - Assembly Instructions; Cart Base Assembly

6
ASSEMBLY INSTRUCTIONS
Lowes.com/masterforge
3. Attach bottom shelf (Q) to the left cart assembly
(V) and right cart assembly (O).
1. Attach two casters (U) to left cart assembly (V)
and secure with wrench (HH).
2. Attach two lock casters (P) to right cart
assembly (O) and secure with wrench (HH).
1
1
V
O
Q
3
1
1
2
O
HH
P
2
1
1
2
V
HH
U
1
Hardware Used
Wrench
(not to scale)
x 1
HH
Hardware Used
Wrench
(not to scale)
x 1
HH
