13
Lowes.com/masterforge
ASSEMBLY INSTRUCTIONS
10. Attach the left side shelf bracket (H) to the
left of the burner box (A) and the right side
shelf bracket (E) to the right of the burner
box with 2 screws (AA) on each bracket.
Hardware Used
AA
AA
3/16-24 x 1/2 in.
Screw
x 8
Complete Steps 11 - 13 to complete assembly
of the left side shelf (G) and right side shelf (F).
11. Move the side shelves from front to back,
making sure the screw on the side shelf
brackets t inside the holes on the side
shelves.
10
H
H
E
E
11
G
F
Side shelf
bracket
Side shelf
To Next Page
