PARTS LIST/IDENTIFICATION:
PART NUMBER DESCRIPTION QUANTITY
Dome Parts
A Dome 1
B Handle 1
C Wing Nut, Lock Washer, Washer 2
D Heat Indicator 1
E Large Bolt 1
F Air Damper 1
G Nut & Bolt 1
Middle Body Parts
H Middle Body 1
I Grill Racks 3
J Grill Rack Brackets 9
K Bracket Bolts 9
L Handles 2
M Wing Nut, Lock Washer, Washer 4
N Wood Door 1
O Water Bowl 1
Lower Body Parts
P Lower Body 1
Q Wood Chip Bowl 1
R Spring Clips (Attached To Body) 4
S Brackets 3
T
Bracket Bolts (3-Brackets, 2-Element Bracket)
5
U Side Shelf 1
V Bolt, Nut, Lock Washer, Washer 4
W Electric Element 1
X Element Bracket 1
Y Electric Controller Unit 1
Z Heat Shield 1
AA Ash Pan 1
Leg & Wheel Parts
BB Front Legs 2
CC Bottom Rack 1
DD Wheel Legs 2
EE Wheels 2
FF Rubber Feet 2
GG Large Stainless Steel Nuts 4
HH Leg Mounts 4
Please read all instructions and warnings before assembly.
TOOLS REQUIRED:
Phillips head screwdriver, crescent wrench or socket wrench set.
NOTE: Do not completely tighten screws until the assembly is complete.
For easier assembly we recommend two people assemble this product.
11
Kickin Cajun Seasoning for Frying Turkeys
Steak Seasoning for Frying or Grilling
BBQ Rub for Smoking Ribs and More
Injectable Turkey Marinades
Garlic & Herb or Buttery Creole
ALSO TRY: Sizzlin Steak Marinade, Glazing Honey Injectable
Marinade, Kickin Cajun Hot Wing Sauce, Hot and Spicy BBQ
Sauce and Grandma’s Mild BBQ Sauce
Fish & Seafood Batters
Original Crispy Batter
Original Crispy Cajun Batter
Southern Style Corn Meal Breading
Gift Packs
Spices, Marinades, BBQ Sauces and Batters
Try Southern Secrets
Try ‘Em All…www.masterbuilt.com
Turkey Cookin’ Kit Steak & BBQ Cookin’ Kit Fish & Wing Cookin’ Kit
