Parts List
NO. QT Y. DESCRIPTION
1 2 Smoking/Warming Racks
2 2 Smoke + Sear Grates
3 1 Temperature Gauge
4 1 Lid Assembly
5 1 Handle Tube
6 1 Heat Manifold Support
7 1 Temperature Probe Bracket
8 1 Temperature Probe
9 1 Body Assembly
10 3 Lid/Door Switch
11 1 Side Shelf Assembly
12 1 Controller Assembly
13 1 Bottom Tray Assembly
14 1 Left Rear Leg Assembly
15 1 Left Front Leg Assembly
16 1 Grease Tray
17 1 Side RH Leg Brace
18 1 Right Rear Leg
19 1 Right Front Leg
20 1 Wheel Axle with Lock Nut / 3 Washers / 2 Bushings
21 2 8” Wheel
22 1 Bottom Shelf Assembly
23 2 3” Caster
24 1 Back Leg Brace
25 1 Front Leg Cross Brace
26 1 Side LH Leg Brace
27 1 Front Shelf Assembly
28 3 Tool Hanger
29 1 Hopper Lid Handle Washer
30 1 Hopper Lid Handle
31 1 Hopper Heat Shield - Top
NO. QT Y.
DESCRIPTION
32 1 Hopper Lid Latch
33 1 Hopper Assembly - Top
34 2 Hopper Gasket
35 2 Front/Rear Fire Brick
36 1 Left Fire Brick
37 1 Right Fire Brick
38 1 Hopper Assembly - Middle
39 1 Grill Heat Intake Fiber Spacer
40 1 Heat Intake Slide (Large)
41 1 Air Intake Slide (Small)
42 1 Hopper Door Latch
43 1 Charcoal Grate Assembly
44 1 Fan Brace
45 1 Hopper Heat Shield - Bottom Rear
46 1 Hopper Door Assembly
47 1 Fan
48 1 Fan Guard
49 1 Hopper Assembly - Bottom
50 1 Hopper Heat Shield - Bottom Front
51 1 Ash Tray Assembly
52 1 Manifold Ash Grate
53 1 Hopper Lid Assembly
54 1 Hopper Shrouding
55 2 Lid Handle Base
56 1 Antenna
57 1 Meat Probe
58 2 Lid Handle Washer
59 1 Heat Manifold (Grill)
60 1 Heat Manifold Base
61 1 Cord Managment Bracket
1 Power Cord - Not Shown
DO NOT RETURN TO RETAILER for assembly assistance, missing or damaged parts. Please
contact MASTERBUILT Customer Service at www.masterbuilt.com/pages/support. Please have
the model number and serial number available. These numbers are located on the silver rating
label on the grill.
STOP
• BEFORE ASSEMBLY READ ALL INSTRUCTIONS CAREFULLY.
• Assemble on a clean flat surface.
• Recommend assembling on cardboard to avoid oil residue on floors or scratches.
• Gloves recommended for assembly. Hopper gasket is fiberglass and will irritate skin.
• Tools needed: Phillips head screwdriver, adjustable wrench, 19mm socket wrench.
• Approximate assembly time: 1 hour, 45 minutes.
• Recommend two people assemble to increase ease and reduce assembly time.
• Actual product may differ from picture shown.
• It is possible that some assembly steps have been completed in the factory.
• Remove all printed labels from the grill and hopper before use.
To Next Page
