Masterbuilt MB20040722 User Manual

CART
RAISING AND LOWERING THE CART
From the lower position:
1. Place foot on the bottom leg.
2. Release the latch
3. Using the side shelf, pull the grill up.
4. Raise the top leg in the lock position.
Note: Do not remove foot from bottom leg until grill is fully
locked in the raised position.
From the raised position:
1. Lock the lid.
2. Place foot on the bottom leg.
3. Pull side shelf toward you while releasing the latch.
4. Lower the grill until it makes contact with cart latch.
Note: Do not remove foot from bottom leg until grill is fully
locked in the lowered position.
5. Unfold tow handle and lock.
6. Grill is now ready to be transported.
14
Operating Instructions
PRESS HERE TO
RELEASE LATCH
UNFOLD TOW HANDLE
LOCK TOW HANDLE
READY TO GO
TOW HANDLE
RAISED POSITION
RAISED POSITION
LOWERED POSITION
LOWERED POSITION
NO
YES
1
2
3
