Masterbuilt MB20040722 - Parts Diagram; Parts List

Parts Diagram
4
1
2
3
4
5
6
7
8
9
10
11
12
13
14
16
17
18
19
20
21
22
23
24
15
NO. QT Y.
DESCRIPTION
13 1 Lid Handle Liner
14 1 Charcoal Grate
15 1 Grease Tent
16 1 Cooking Grate
17 2 Handles (MODELS MB20040522 and MB20040622)
18 1 Right Shelf
19 1 Metal Shelf Support Rear
20 1 Metal Shelf Support Front
21 1 Body
22 1 Body Spring
23 2 6” Wheels
24 2 Wheel Axle
25 1 Grease Cup
NO. QT Y.
DESCRIPTION
1 1 Temperature Gauge
2 2 Lid Handle Bezel
3 1 Lid Handle
4 1 Charcoal Hopper Lid
5 1 Charcoal Hopper
6 1 Manifold
7 1 Body Liner
8 1 Left Shelf
9 4 Mica Gaskets
10 1 Leg Support
11 1 Foot Tube
12 1 Lid
